This paper reviews commonly used parameters and prediction models for assessing the permeability of granular soils. Following a review of published models for prediction of soil permeability, a dimensional homogenous transformation model for a-priori estimation of soil permeability was calibrated using a large database (CG/KSAT/7/1278) comprising permeability data for a wide range of granular soils sourced from over 50 publications. The new transformation model requires knowledge of the void ratio and gradation of the material to make estimates of the soil permeability. The prediction accuracy of the calibrated model was then assessed alongside that of other empirical and semi-empirical models also calibrated using CG/KSAT/7/1278. The potential influences of void ratio, key gradation parameters and permeability test type on the prediction accuracy of the proposed model are also examined. The paper shows that while the fitted constants in the proposed transformation model are affected to varying extents by the aforementioned parameters, it does offer reasonable predictions of permeability with only knowledge of the void ratio and material gradation required.

Particle breakage in soils is a well-recognised behaviour. Conventional methods for quantifying the breakage process rely on calculating the area between the particle size distribution (PSD) curves produced before and after crushing. A key aspect of breakage is understanding the process across the different size/sieve fractions. Grading entropy coordinates allow for the representation of any PSD to be shown as a single point on a Cartesian plane and are able to track grading evolution with relative ease. In this study, grading entropy coordinates are compared to three commonly used breakage indices (Br, Br* and IG). It is shown that grading entropy coordinates are advantageous over the traditional indices in quantifying subtle changes in the PSD evolution and directly provide further insight with regards to the individual fraction sizes. It is also discussed that conventional breakage indices rely on relative measures and are dependent on assumptions of an initial and/or final PSD. In contrast, grading entropy coordinates depend only on the characteristics of the (current) PSD curve. It was also observed that the breakage evolution captured by the entropy coordinates is able to determine the rate at which differently sized particles break as differently sized particles take on stress. Moreover, it is suggested that entropy coordinates may also stress path dependency, a feature not present in conventional indices.

The ground is a natural grand system; it is composed of myriad constituents that aggregate to form several geologic and biogenic systems. These systems operate independently and interplay harmoniously via important networked structures over multiple spatial and temporal scales. This paper presents arguments and derivations couched by the authors, to first give a better understanding of these intertwined networked structures, and then to give an insight of why and how these can be imitated to develop a new generation of nature-symbiotic ground engineering techniques. The paper draws on numerous recent advances made by the authors, and others, in imitating forms (e.g. synthetic fibres that imitate plant roots), materials (e.g. living composite materials, or living soil that imitate fungi and microbes), generative processes (e.g. managed decomposition of construction rubble to mimic weathering of aragonites to calcites), and functions (e.g. recreating the self-healing, self-producing, and self-forming capacity of natural systems). Advances are reported in three categories of Materials, Models, and Methods (3Ms). A novel value-based appraisal tool is also presented, providing a means to vet the effectiveness of 3Ms as standalone units or in combinations.

Sand−rubber mixture (SRm) behaviour is affected by rubber content (RC) while dissipation in sands is caused by inter-particle sliding. Dissipation in SRm is as, or more significant than in sands. However, the mechanisms of dissipation in SRm are not well understood. In this study, one-dimensional compression tests on sand samples with RC of 0, 15, 30, 45 and 100% by mass were performed on a standard oedometer. In addition, a SRm with RC of 30% was tested on a mini-oedometer placed inside an X-ray scanner and three-dimensional images of the internal structure of the material were acquired at three stages during loading and unloading. Image analysis was used to infer particle-scale measurements and provide experimental evidence to help explaining the energy dissipation mechanisms for SRm. It is postulated here that energy dissipation in these mixtures is dominated by inter-particle sliding at initial stages of loading, but once rubber particles fill the void spaces between the sand, deformation and dissipation mechanisms are dominated by the deformation of the rubber particles.

This paper presents an investigation into the effects of particle-size distribution on the critical state behavior of granular materials using Discrete Element Method (DEM) simulations on both spherical and non-spherical particle assemblies. A series of triaxial test DEM simulations examine the influence of particle-size distribution (PSD) and particle shape, which were independently assessed in the analyses presented. Samples were composed of particles with varying shapes characterized by overall regularity (OR) and different PSDs. The samples were subjected to the axial compression through different loading schemes: constant volume, constant mean effective stress, and constant lateral stress. All samples were sheared to large strains to ensure that a critical state was reached. Both the macroscopic and microscopic behaviors in these tests are discussed here within the framework of the anisotropic critical state theory (ACST). It is shown that both OR and PSD may affect the response of the granular assemblies in terms of the stress-strain relations, dilatancy, and critical state behaviors. For a given PSD, both the shear strength and fabric norm decrease with an increase in OR. The critical state angle of shearing resistance is highly dependent on particle shape. In terms of PSD, uniformly distributed assemblies mobilize higher shear strength and experience more dilative responses than specimens with a greater variation of particle sizes. The position of the critical state line in the e-p’ space is also affected by PSD. However, the effects of PSD on critical strength and evolution of fabric are negligible. These findings highlight the importance of particle shape and PSD that should be included in the development of constitutive models for granular materials.

The behavior of granular materials is very complex in nature and depends on particle shape, stress path, fabric, density, particle size distribution, amongst others. This paper presents a study of the effect of particle geometry (aspect ratio) on the mechanical behaviour of granular materials using the Discrete Element Method (DEM). This study discusses 3D DEM simulations of conventional triaxial and true triaxial tests. The numerical experiments employ samples with different particle aspect ratios and a unique particle size distribution (PSD). Test results show that both particle aspect ratio (AR) and intermediate stress ratio (b=(σ2’-σ3’)/(σ1’-σ3’)) affect the macro-and micro-scale responses. At the macro-scale, the shear strength decreases with an increase in both aspect ratio and intermediate stress ratio b values. At the micro-scale level, the fabric evolution is also affected by both AR and b. The results from DEM analyses qualitatively agree with available experimental data. The critical state behaviour and failure states are also discussed. It is observed that the position of the critical state loci in the compression (e-p’) space is only slightly affected by aspect ratio (AR) while the critical stress ratio is dependent on both AR and b. It is also demonstrated that the influence of the aspect ratio and the intermediate stress can be captured by micro-scale fabric evolutions that can be well understood within the framework of existing critical state theories. It is also found that for a given stress path, a unique critical state fabric norm is dependent on the particle shape but is independent of critical state void ratio.

Soil particles may be lost through dissolution, degradation or erosion. Regardless of the process of loss, there follows a change in soil structure both in terms of phase composition and grading. In this paper, the influence of size and amount of particle loss on phase composition at two stresses is investigated. The tests are performed on sand–salt mixtures, loaded in a modified permeation oedometer and subsequently dissolved. Changes in overall volume and void ratio are presented. Two significant observations about the volumetric consequences of particle loss can be made. First, overall volume changes are directly related to the amount of dissolved particles and to a lesser extent, the size of particle lost. Second, particle loss leads to an increase in void ratio; the magnitude of the increase is related to the amount of dissolved particles but appears not to be sensitive to either the size of particle lost or the pre-dissolution void ratio. Based on the observed response and a dissolution-induced void change parameter, the influence of different mechanisms of volume change is discussed. Tests were performed at two different vertical stresses with no discernible influence on void ratio change.

Previous research studies have used either physical experiments or discrete element method (DEM) simulations to explore, independently, the influence of the coefficient of inter-particle friction (μ) and the intermediate stress ratio (b) on the behaviour of granular materials. DEM simulations and experiments using photoelasticity have shown that when an anisotropic stress condition is applied to a granular material, strong force chains or columns of contacting particles transmitting relatively large forces, form parallel to the major principal stress orientation. The combined effects of friction and the intermediate stress ratio upon the resistance of these strong force chains to collapse (buckling failure) are considered here using data from an extensive set of DEM simulations including triaxial and true triaxial compression tests. For all tests both μ and b affected the macro- and micro-scale response, however the mechanisms whereby the force chain stability was improved differ. While friction clearly enhances the inherent stability of the strong force chains, the intermediate stress ratio affects the contact density and distribution of orthogonal contacts that provide lateral support to the force chains.
